GoldenEar Triton One.R Speakers

Reference Floorstanding Tower with Built-in 1600 Watt ForceField Subwoofer

The Triton One.R is an extraordinary reference quality loudspeaker that is a smaller, less expensive follow up to our award winning flagship, the Triton Reference. The 54" tall Triton One.R's upgraded technology includes a 56 bit DSP engine for the powered sub, a fully balanced crossover design, high-end film capacitors, advanced cabinet design, and much more.

The Triton One.R's built-in subwoofer section is powered by a 1600 watt GoldenEar SuperSub digital amplifier. The amp drives three racetrack shaped active subwoofer drivers with huge magnet structures, coupled to dual (per side) side-mounted 7" x 10" quadratic planar infrasonic bass radiators to extend the low frequency response. These are inertially balanced (two on each side) in order to minimize cabinet movement, for more detailed sound.

Book a demo
Devialet Expert 220 integrated amplifier
The Details

SPECIFICATIONS


TRITON REFERENCE

WEIGHT
49.8 kg

DIMENSION (H X W X D)
23.36 cm x 47.6 cm x 147.27 cm (W x D x H)
(height is with base installed, no spikes)

Base: 13-5/8" W x 22-1/4" D

FREQUENCY RESPONSE
12 Hz – 35 kHz

EFFICIENCY
93.25 dB

NOMINAL IMPEDANCE
Compatible with 8 ohms

DRIVER COMPLEMENT
  • Three 6" x10" long-throw quadratic Reference subwoofers, coupled to:
  • Four - 9-1/2"x10-1/2" Quadratic Planar Infrasonic Radiators
  • Two - 6˝ High-Definition Cast-Basket Reference Mid/Bass Drivers, One High-Gauss Reference High-Velocity Folded Ribbon (HVFR™) Tweeter



RECOMMENDED AMPLIFICATION
20 – 750 watt/channel







TRITON ONE.R

WEIGHT
36.3 kg (product) | 47.6 kg (shipping)

DIMENSION (H X W X D)
14.6 cm (W - front) x 20.3 cm (W - rear) x 42.3 cm (D) x 137.2 cm (H)

Base: 31.4 cm (W) x 50.2 cm (D)

FREQUENCY RESPONSE
13 Hz - 35 kHz

EFFICIENCY
92 dB

NOMINAL IMPEDANCE
Compatible with 8 ohms

DRIVER COMPLEMENT
  • Three - 5˝ x 9˝ Long-Throw Quadratic Reference Subwoofer Bass Drivers, coupled to:
  • Four - 7˝ x 10˝ Quadratic Planar Infrasonic Radiators
  • Two - 5-1/4˝ High-Definition Cast-Basket MVPP™, Focused Field, Reference Upper-Bass/Mid Drivers
  • One - High-Gauss HVFR™ High-Velocity Reference Folded Ribbon Tweeter

RECOMMENDED AMPLIFICATION
20 - 650 watt/channel

BUILT-IN SUBWOOFER POWER AMPLIFICATION
1600 watt SuperSub Amplifier





TRITON FIVE

WEIGHT
18 kg (product) | 25.4 kg (shipping)

DIMENSION (H X W X D)
16.8 cm (W - front) x 20.5 cm (W - rear) x 31.3 cm (D) x 112.4 cm (H)

Base: 27.9 cm (W) x 41.9 cm (D)

FREQUENCY RESPONSE
26 Hz - 35 kHz

EFFICIENCY
90 dB

NOMINAL IMPEDANCE
Compatible with 8 ohms

DRIVER COMPLEMENT
  • Two - 6˝ High-Definition Cast-Basket
    Mid/Bass Drivers, coupled to:
  • Four - 8˝ Planar Sub-Bass Radiators
  • One - HVFR™ High-Velocity Folded Ribbon Tweeter





RECOMMENDED AMPLIFICATION
15 - 400 watt/channel








High-Velocity Folded Ribbon Tweeter (HVFR)
  • Tweeter Diaphragm is a High Temperature Film
  • High-Power Neodymium Magnets
  • Squeezes/Pressurizes Air Instead of Pushing It
  • Greater Control, Smoother More Extended Response
  • Vanishingly Low Distortion
  • Dramatically Improved Dynamic Range and Detail
  • Superb Dispersion Characteristics





High-Definition Cast-Basket Bass/Midrange Driver
  • GoldenEar Multi-Vaned Phase Plug (MVPP) Design
  • Rigid Free-Flow Cast-Basket Chassis
  • Proprietary Computer Optimized Cone Topology
  • High-Gauss Magnet Assembly (Focused Field on Triton One.R)
  • 1˝ High-Temperature Kapton Former Voice Coil
  • Extremely Extended Resonant-Free Linear Frequency Response Characteristics



5˝ x 9˝ Quadratic Sub-Bass Driver
  • Ultra-Long Throw
  • Glass Fiber and Nomex® Composite Cone
  • Huge, High-Gauss Magnet Assembly
  • 1.5˝ High-Temperature Aluminum Voice-Coil
  • Quadratic Cone topology for Maximum Cone Surface Optimization







Quadratic Planar Infrasonic Radiators
  • Quadratic Planar Radiators, Four on Triton One, Two on Triton Two+ and Three+
  • Pressure-Coupled Loading Extends Usable Bass Performance to the Infrasonic Region
  • Performs Like a well-Tuned Transmission Line but with Superior transient Performance and Control
  • Inertially-balanced opposing design
