KEF Reference 5 Non-Meta (Display)

Color
Satin Walnut Silver
Flagship three-way floorstander

If you're serious about experiencing the ultimate in sound reproduction, the magnificently authoritative Reference 5 exemplifies the passion for innovation that underpins KEF’s design philosophy.

With four bass drivers and the latest Uni-Q mid and tweeter, the REFERENCE 5 exemplifies KEF's passion for innovation. Whether it's music or film, it reveals the irresistible emotional power of the performance every time.



Note: For more info, please contact us via live chat from 11am to 7pm in the bottom left corner of the screen.


Please note these are store display sets that have been thoroughly tested by ATLAS and assessed to be in good condition for sale. Items are sold as is and may be without their original packaging and accessories. Available only in Walnut Silver (Non Meta version). Warranty: 2 Years Limited. (Minor cosmetic defect.) Please contact us for more information before purchasing.

Available only at Atlas @ Harper.

Clearance Sale     Reference Series

Warranty

2 Years Limited Warranty by ATLAS.

Return Policy

All clearance sale items sold are non-exchangeable, non-returnable and non-refundable.

Reference 5

This three-way floorstander aligns four powerful 165mm (6.5 inch) bass drivers with KEF's latest 125mm (5 inch) Uni-Q array and the new vented 25mm (1 inch) aluminium dome tweeter. Lows are reproduced with consummate agility and control, integrating with the midrange to create spine-tingling accuracy and depth.

Always innovating

Since the first Reference speaker, KEF engineers have continued to innovate using what is possible with The Reference. Ground-breaking in its first incarnation, each subsequent iteration of The Reference has added to the world’s knowledge of the science of acoustics.

Designed, engineered and handcrafted in UK

Since 1961, we have been creating remarkable award-winning loudspeakers at our UK home in Maidstone, Kent. As our flagship HiFi speakers, The Reference is still being designed, engineered, and handcrafted in Maidstone today.

SPECIFICATIONS


Weight
60.2kg (132.7lbs)

Dimension (H X W X D)
H x W x D with grille and terminal :
1350 x 205 x 470 mm (53.1 x 8.0 x 18.5 in. )

H x W x D with grille, terminal & plinth :
1397 x 349 x 470 mm (55 x 13.7 x 18.5 in.)

Design
Three-way bass reflex

Unit Measurement
Pair

Frequency Range
Typical in room bass response: 25Hz (-6dB)
Free Field - Short port: 35Hz - 45kHz (-6dB)
Free Field - Long port: 32Hz - 45kHz (-6dB)



Frequency Response
40Hz - 35kHz (±3dB)

Crossover Frequencies
350Hz, 2.8kHz

Maximum Output
116 dB (peak sound pressure level at 1m with pink noise)

Amplifier Class
50-400W

Sensitivity 90DB (2.83V/1M)
Harmonic distortion2nd & 3rd harmonics (90dB, 1m)
<0.5% 40Hz – 100kHz
<0.2% 200Hz – 10kHz

Impedance
8 Ohms (min.3.2 Ohms)




Drive Units
Uni-Q driver array:
HF: 25mm (1in.) vented aluminium dome
MF: 125mm (5in.) aluminium
Bass units: LF: 4 x165mm (6.5in.) aluminium

Crossover Frequencies
350Hz, 2.8kHz
